HSZ Series

The HSZ series of industrial control transformers are designed for applications requiring special mounting and are available in ratings from 1 through 10 KVA.

Features

  • Two case styles available, UL-3R and NEMA-12
  • Stainless Steel (NEMA 3R and 4X) Enclosures are also available
  • UL Class 180°C insulation system, 80°C temperature rise under full load
  • Meets or exceeds NEMA regulation standards
  • Copper magnet wire windings
  • Encapsulated

PDF Files

HSZ Series Specifications



HSZ Series

Group 1: 240/480, 230/460, 220/440 Volt Primary, 120/115/110 Volt Secondary, 50/60 Hz.

Catalog Number
(NEMA-3R)
 Catalog Number
(NEMA-12)		 KVA Height (in) Width (in) Depth (in)
HZ1000 HZ12-1000 1 12 10 7
HZ1500 HZ12-1500 1.5 12 10 7
HZ2000 HZ12-2000 2 12 10 7
HZ3000 HZ12-3000 3 17 14 9
HZ5000 HZ12-5000 5 17 14 9
HZ7500 HZ12-7500 7.5 17 14 9
HZ10000 HZ12-10000 10 17 17 12



Group 2: 230/460/575 Volt Primary, 115/95 Volt Secondary, 50/60 Hz.

Catalog Number
(NEMA-3R)
 Catalog Number
(NEMA-12)		 KVA Height (in) Width (in) Depth (in)
HZ1000A HZ12-1000A 1 12 10 7
HZ1500A HZ12-1500A 1.5 12 10 7
HZ2000A HZ12-2000A 2 12 10 7
HZ3000A HZ12-3000A 3 17 14 9
HZ5000A HZ12-5000A 5 17 14 9
HZ7500A HZ12-7500A 7.5 17 14 9
HZ10000A HZ12-10000A 10 17 17 12



Group 3: 480 Volt Primary, 240 Volt Secondary, 50/60 Hz.

Catalog Number
(NEMA-3R)
 Catalog Number
(NEMA-12)		 KVA Height (in) Width (in) Depth (in)
HZ1000R HZ12-1000R 1 12 10 7
HZ1500R HZ12-1500R 1.5 12 10 7
HZ2000R HZ12-2000R 2 12 10 7
HZ3000R HZ12-3000R 3 17 14 9
HZ5000R HZ12-5000R 5 17 14 9
HZ7500R HZ12-7500R 7.5 17 14 9
HZ10000R HZ12-10000R 10 17 17 12
